Chapter 3 Using the Operator Panel
3-20
Display the desired baud rate and press the
ENTER
key.
Press the
MENU
key. The message display returns to
Ready.
Changing Network Interface Parameters
This printer is equipped with the network interface.
For details on networking, refer to the “Quick Configuration
Guide”.
Press the MENU key.
Press the 3 or 4 key repeatedly until Interface >
appears. One of the interface names shown below ap-
pears, indicating the current interface.
Parallel (default)
Serial
Network
Option (only when an optional network interface
card is installed)
Press the ENTER key. A blinking question mark (?) ap-
pears.
Press the 3 or 4 key repeatedly until Network ap-
pears.
Press the
ENTER
key again.
Press the 2 key. Each time the 3 or 4 key is pressed,
the display changes as shown below.
The following example explains how to activate TCP/IP
protocol to connect the printer in the network. You can
select Netware or EtherTalk in a similar manner.
If TCP/IP is currently displays Off, select On using the
3 or 4 key. Press the ENTER key again.
Interface
?Parallel
Interface
?Network
9
10
1
2
3
4
5
>NetWare
On
>TCP/IP
On
>EtherTalk
Off
>Network Status
Page On
If turns ON, print the
standard Network Inter-
face Status Page after
the Printer Status Page.
See
page 3-10
.
>Opt. StatusPage
On
If turns ON, print the op-
tional Network Interface
Status Page after the
Printer Status Page.
See
page 3-10
.
>TCP/IP >
On
>TCP/IP
? Off
>TCP/IP >
On
6
7
