Chapter 6 Maintenance

6-4

Remove the blue colored cleaning brush.

Pull up the lock lever on the left side of the printer, and

open the left cover 1.

Clean the separator by moving the cleaning brush from

left to right along with the separator.

Replacing of toner and cleaning of the internal parts of

the printer are completed. Close the front cover and the

left cover 1.

Allow approximately five minutes before using the

printer until the main charger unit has dried up.
